EMAX EP10D120V1 : Alternating 10 HP 76 CFM 120 Gal. Horizontal Duplex

Name: EMAX EP10D120V1 : Alternating 10 HP 76 CFM 120 Gal. Horizontal Duplex
Brand: Emax
SKU: EP10D120V1
Price: 8199 USD
Availability: InStock

Emax

$8,199.00

Write a Review

SKU:: EP10D120V1
Shipping:: Free Shipping
Voltage:: 208V
Voltage:: 230V
Tank Orientation:: Vertical
Phase:: 1 Phase
CFM:: 71-80
HP:: 10 HP
Motors:: Simplex
Tank Size:: 120 Gal

Product Description

This Industrial Plus 10 HP 2 Stage V4 1 Phase Vertical 120 Gallon Piston Air Compressor is designed for up to 50,000 hours of commercial or industrial use with proper maintenance. This unit features our low RPM pumps and delivers 38 CFM @ 100 PSI. Our unit features automatic or continuous run functionality and is SUPER COOL & SUPER QUIET!

COMPRESSOR PUMP

At the core of our Emax compressors is our pump. These pumps are SUPER quiet in operation and built to last! We start with a solid cast iron crankcase. Unlike some competitor’s aluminum body crankcases our solid cast iron crankcase will ensure stable crankshaft alignment and will handle more work load under heavy load conditions.

Our pump also features a precision balanced solid cast iron crankshaft with Timken-Style stainless steel roller bearings on the front and rear of the crankshaft to ensure smooth & efficient operation with less drag and less energy use.

Our pumps also feature several other key components that ensure durability and performance!

All steel connecting rods with replaceable rod bearing inserts. This allows our rods to be rebuilt! 99% of our competitors now use throw-away aluminum connecting rods in their pumps that have no re-build capability.
Removable 100% cast iron cylinders. These solid cast iron cylinders are more stable under heavy workloads and do not warp from heat. Most of our competitors are using aluminum cylinders with a pressed-in sleeve that warp under extreme heat. This makes competitor pumps good for about a 40-50% duty cycle while claiming a 100% duty cycle. Most of the pumps with aluminum cylinders must be replaced in 1-2 years because they would not hold up under heavy use. Not our Air pumps! Our solid cast iron cylinders can take the heat and are designed to perform on heavy load demands.
All cast iron cylinder heads. Cast iron heads are more durable and dependable for trouble free operation.
Disc valve design intake and exhaust valves. Disc valves have been around for over 100 years and have been proven to perform. Most of our competitors are using throw-away reed valves which are not nearly as durable and can’t be re-built. Our disc valves come right out of the top of the cylinder head where they can be serviced in minutes instead of hours like reed valves.
Top quality compression and oil rings. Our rings ensure performance with low oil carry over (1-5 PPM).
Precision ground pistons machined to tight tolerances ensures low oil carry over.
Premium non-absorbent gaskets prevent oil seepage from pump.
All cast iron flywheel with built-in fan. The extra weight of our cast iron flywheel during run cycle gives the pump more throw on the compression stroke which will result in fewer loads on the electric motor. Some manufacturers use aluminum flywheels that do not have the proper weight ratio to give the proper throw on the compression stroke when the pump is running.
Built-in head unloaders. These unloaders are built into the intake valve assembly on the compressor head and perform a valuable function. They unload or open the intake valves under constant run applications. This feature reduces internal pump heat from compression because the intake valve is held open throughout the unloading cycle. This allows fresh air to come into the cylinder chamber. Under the compression stroke, the unloader holds the intake valve open allowing the air to blow back out the intake filter. This fresh air absorbs the heat out of the pump under heavy workloads.
Built-in inter-cooler and after-coolers. The inter-cooler allows air to be cooled between stages while the air cooled after-cooler provides a second cooling stage that cools the air before it goes into the tank. Our after-cooler also includes an all copper main feed line from the pump into the tank.

Specifications
Specifications

Specifications

Grade	Commerical
Voltage	208-230V
Phase	1-Phase
CFM	38
Tank Size	120 Gal

Specifications

Voltage 208V

Voltage 230V

Tank Orientation Vertical

Phase 1 Phase

CFM 71-80

HP 10 HP

Motors Simplex

Tank Size 120 Gal
