Max. Tire Diameter | 90.5” (2300mm) |
Max. Tire Width | 42” (780mm) |
Rim Diameter Range | 14”-46” |
Electric Specifications | 208-230VAC, 3ph, 60Hz, 15Amp |
Hydraulic Motor Power | 2.0 HP (1.5kW) |
Chuck Rotation Motor Power | 1.7-2.4 HP (1.3-1.8 kW) |
Chuck Rotation Speed | 5-11 rpm |
Max. Wheel Weight | 3300 lbs (1500kg) |
Max. Overall Dimensions | 88”(w) x 79”(d) x 59”(h) |
Weight with Standard Accessories | 1698 lbs (770 kg) |
Specifications
Type Heavy Duty
Clamping Chuck-Clamp
Power Electric
